    Ubiquiti UISP Console [UISP-Console]

    UISP-Console by Ubiquiti
    $299.00 - $299.00
    $299.00
    $299.00 - $299.00
    $299.00
    Extend Product Protection
    UISP host console with an integrated switch and multi-gigabit Ethernet gateway.

    The UISP® Console is designed to support small to moderate UISP deployments with its built-in switch equipped with (8) GbE RJ45 LAN ports. The UISP Console also serves as a high-performance gateway with (1) 10G SFP+ LAN port and (2) WAN ports (10G SFP+ and GbE RJ45) that provide an ample connectivity range capable of supporting the most data-intensive deployments.

    Product Features:
    • (2) 10G SFP+ ports
    • (9) GbE RJ45 ports
    • Powered by an external AC/DC adapter (included)
    • Compact, durable metal casing
    • 1U rack or wall-mountable (kits included)
    • Easy, Bluetooth-powered setup via the UISP Mobile app
    • Pre-installed UISP application

    Product Specifications:

    Mechanical

    • Dimensions: 210.4 x 140.2 x 43.7 mm (8.3 x 5.5 x 1.7")
    • Weight: 1.5 kg (3.2 lb)
    • Enclosure materials: SGCC steel, polycarbonate


    Hardware

    • Processor: Quad-core ARM® Cortex®-A57 at 1.7 GHz
    • Memory: 4 GB DDR4
    • Onboard flash storage: 16 GB eMMC
    • Onboard storage: 128 GB SSD
    • Card slot: (1) microSD
    • Networking interface:
      • (8) LAN: GbE RJ45 ports
      • (1) LAN: 1/10G SFP+ port
      • (1) WAN: GbE RJ45 port
      • (1) WAN: 1/10G SFP+ port
    • Management interface:
      • Ethernet In-band
      • Bluetooth
    • Power method:
      • (1) External AC/DC adapter
      • (1) Power TransPort DC input 27V DC, 1.5A
    • Power supply: 24V DC, 2.5A power adapter (included)
    • Supported voltage range: 24—28V DC
    • Max. power consumption: 30W
    • ESD/EMP protection: Air: ± 15kV, contact: ± 8kV
    • Operating temperature: -10 to 50° C (14 to 122° F)
    • Operating humidity: 5 to 95% noncondensing
    • Certifications: CE, FCC, IC
