    Siklu EtherHaul E-Band 70/80GHz 2ft Heated Antenna

    EH-ANT-2ft-H by Siklu
    Sold out
    $1,237.95 - $1,237.95
    $1,237.95
    $1,237.95 - $1,237.95
    $1,237.95
    Extend Product Protection
    Product Specifications:
    • Compatibility: EH-710T/710TX (EXT versions), EH-1200T/TX, EH-1200FX, EH-2500F/FX, EH-8010FX
    • Frequency Range: 7GHz – 86GHz
    • Regulatory Compliance:
    • ETSI: EN 302 217-4-2 V1.5.1 Class 3
    • FCC: 47CFR101
    • Gain: 50dBi ± 2dB
    • 3dB Beam: 0.5°
    • Polarization: Linear Vertical / Horizontal
    • RF Input power: 10W (max)
    • Interface: Circular waveguide E-band
    • Radome: ABS
    • DC input power: 48VDC, 55W (screw terminal inside the controller)
    • DC input cable: 1 pair, diameter 0.79/0.197in (2/5mm) (min./max.).
    • Temperature control: The controller enables the heater before temperatures fall below freezing, and disables the heater after the temperatures have risen above freezing.
    • Disable function (force-off): EtherHaul 8010 radios can force the controller off (a USB cable is included to connect the controller to the radio).
    • Size (inches): 5.9"x4.3"x2.7” (15cmx11cmx7cm)
    • Weight: 1.2 Lbs (550 gr)
    Product Includes:
    (1) Siklu EtherHaul 2ft E-Band Heated Antenna
