Positron Access G1002-M+ G.hn To Gigabit Ethernet Bridge 802.3af GigE Powered From GAM

The Positron G1002-M+ (copper) G.hn Bridge to Gigabit Ethernet comes with two (2) Gigabit Ethernet port to connect the Residential Gateway  (RG). The  Gigabit Ethernet Port labelled as GE1 supports POE / POE+ to power an external device.

Product Specifications:

• Dimensions: 3.7” Width x 1.35” Height x 6.7” Depth / 95mm W x 34.3mm Hx 169.5mm D
• Power: 48VDC / 1A power adapter (110-220VAC), 35Wmaximum
• Certification: CE Mark, FCC Part 15 Class B
• Operating Temperature: 0 ̊C to +40 ̊C/ Storage: -25 ̊C to +80 ̊C
• Operating Humidity: 5% to 95% relative, non-condensing G.hn Specification
• G.hn Standards: G.hn Wave-2 Client, based on GigaWireAlliance specification and fully compliant with the following ITU-T standards, G.9960 Amendment 2 -System Architecture and PHY Layer, G.9961 Data Link Layer, G.9962 Management, G.9964 PSD
• Ease of Deployment: Support G.hn overa single copper pair (SISO mode)or over two copper pairs (MIMO mode)
• Ease of Operation:  Automatic firmware and configuration management via the Positron GAM
• Encryption: AES-128 encryption with individual keys for each end-node under the control of the Positron GAM acting as the Master Node
• Modulation and Frequency Band: Band Notching function allows cohabitation with legacy VDSL2 over the same copper pair
• Bandwidth Management: Up to 1.7 Gbps with Dynamic Bandwidth Allocation to optimize throughput based on nature of traffic flows with TDD Multiplexing for programmable upstream / downstream ratio
• Reliability and Resiliency: State of the art LDPC Forward Error Correction (FEC)

Product Includes:

(1) G1002-M+

(1) 48V Wall Adapter
